High-Temperature Aviation Silicone Tape
General Information
FlameShield™ Aviation Silicone Tape is a self-extinguishing non-flammable tape without an adhesive specifically designed for aviation & avionics use. Forms an excellent seal that is weather / water / air-tight when wrapped around electrical connections and connectors, cable and wiring splices, hydraulic hose protection sleeves, duct joints and other electro-mechanical devices. Perfect for avionics. The special silicone formulation of this tape self-fuses (self-amalgamating) when stretched and over-wrapped. Completely flexible at cold temperatures and can be used to +500ºF / +260ºC continuous exposure. Does not support combustion and resists heat, flame, solder drips, slag, sparks, Ozone, UV light and contamination. Can be wrapped over oily or wet surfaces and is an excellent emergency repair tape. Used extensively as an avionics tape for wire and cable bundling and to protect electrical splices and connectors.
FlameShield™ Aviation Silicone Tape is a self-extinguishing non-flammable tape without an adhesive specifically designed for aviation & avionics use. Forms an excellent seal that is weather / water / air-tight when wrapped around electrical connections and connectors, cable and wiring splices, hydraulic hose protection sleeves, duct joints and other electro-mechanical devices. Perfect for avionics. The special silicone formulation of this tape self-fuses (self-amalgamating) when stretched and over-wrapped. Completely flexible at cold temperatures and can be used to +500ºF / +260ºC continuous exposure. Does not support combustion and resists heat, flame, solder drips, slag, sparks, Ozone, UV light and contamination. Can be wrapped over oily or wet surfaces and is an excellent emergency repair tape. Used extensively as an avionics tape for wire and cable bundling and to protect electrical splices and connectors.
Easy & Clean to Use
FlameShield™ Avionics Silicone Tape incorporates a blue marking stripe along its center, making it easy to over-wrap at 50% when taping long lengths. The triangular profile of the tape (thickest in the centre and reducing thickness towards each edge) ensures a smooth finish to the installation with minimum ridging. Easy to remove with a sharp blade while curing or when completely cured and does not leave a gummy or sticky residue the way pressure sensitive adhesive tapes such as standard vinyl electrical tapes or duct tapes do.
FlameShield™ Avionics Silicone Tape incorporates a blue marking stripe along its center, making it easy to over-wrap at 50% when taping long lengths. The triangular profile of the tape (thickest in the centre and reducing thickness towards each edge) ensures a smooth finish to the installation with minimum ridging. Easy to remove with a sharp blade while curing or when completely cured and does not leave a gummy or sticky residue the way pressure sensitive adhesive tapes such as standard vinyl electrical tapes or duct tapes do.
FlameShield™ Avionics
Silicone Tape is available
in a 1" / 25mm and
1.5" / 37mm width.
Each roll contains
432" / 36' / 10.9m of tape.
Silicone Tape is available
in a 1" / 25mm and
1.5" / 37mm width.
Each roll contains
432" / 36' / 10.9m of tape.
How to Install FlameShield™ Aviation Silicone Tape
Lift off the end of the tape from its backing film and then hold the free end onto what the tape is being installed on. With your other hand which is holding the remainder of the tape roll, moderately pull or stretch the tape while over-lapping the wrap. The stretching action activates the special formulation of silicone rubber with the result of the tape self-binding / self-fusing to itself.
Lift off the end of the tape from its backing film and then hold the free end onto what the tape is being installed on. With your other hand which is holding the remainder of the tape roll, moderately pull or stretch the tape while over-lapping the wrap. The stretching action activates the special formulation of silicone rubber with the result of the tape self-binding / self-fusing to itself.
FlameShield™
Aviation Silicone Tape is
Self-Fusing / Self-Bonding
and non-flammable.
Aviation Silicone Tape is
Self-Fusing / Self-Bonding
and non-flammable.
Highly Resistant to Harsh Environments
FlameShield™ Aviation Pure Silicone Tape resists fuels, oils, acids, solvents, UV, Ozone, high-heat, flame exposure, solder drips & sparks. The proprietary silicone formulation provides optimal thermal dispersion (high thermal conductivity) and also gives this tape its iron-oxide red colour.
FlameShield™ Aviation Pure Silicone Tape resists fuels, oils, acids, solvents, UV, Ozone, high-heat, flame exposure, solder drips & sparks. The proprietary silicone formulation provides optimal thermal dispersion (high thermal conductivity) and also gives this tape its iron-oxide red colour.
Fusing / Bonding Time
FlameShield™ Aviation Silicone Tape when over-wrapped under tension adheres to itself and fuses, forming a solid protective shield in 24 hours at room temperature or in just 4 hours at +356ºF / +180ºC. The tape starts to self-fuse / self-bond as it is used, and can be re-seated if necessary within a few seconds of over-wrapping. After a few minutes it is usually necessary to remove the tape with a knife.
FlameShield™ Aviation Silicone Tape when over-wrapped under tension adheres to itself and fuses, forming a solid protective shield in 24 hours at room temperature or in just 4 hours at +356ºF / +180ºC. The tape starts to self-fuse / self-bond as it is used, and can be re-seated if necessary within a few seconds of over-wrapping. After a few minutes it is usually necessary to remove the tape with a knife.
Many Practical Uses
FlameShield™ aviation silicone tape makes for easy hose and cable bundling, replacing tie-wraps. Excellent for fixing leaks in piping and hoses. Makes a good emergency fan belt. Provides excellent weather protection for outdoor electrical and electronic connections. Great as a first-aid tape to hold splints & bandages in place.
FlameShield™ aviation silicone tape makes for easy hose and cable bundling, replacing tie-wraps. Excellent for fixing leaks in piping and hoses. Makes a good emergency fan belt. Provides excellent weather protection for outdoor electrical and electronic connections. Great as a first-aid tape to hold splints & bandages in place.
Contact us for volume
discounts when
purchasing 10 rolls
or more
discounts when
purchasing 10 rolls
or more
The proprietary silicone formulation provides optimal thermal dispersion & contains
no flammable dyes.
no flammable dyes.
FlameShield™ Aviation Silicone Tape
for Aviation & Avionics Wiring Use.
Non-flammable & self-extinguishing.
for Aviation & Avionics Wiring Use.
Non-flammable & self-extinguishing.
AB Technology Group
431 State St. Box 1491, Ogdensburg, NY 13669 USA
116 Albert St - Suite 300, Ottawa, ON K1P 5G3 CANADA
Tel: (610) 906-3549 Fax: (905) 697-9918
431 State St. Box 1491, Ogdensburg, NY 13669 USA
116 Albert St - Suite 300, Ottawa, ON K1P 5G3 CANADA
Tel: (610) 906-3549 Fax: (905) 697-9918
We Accept:
Specifications & Standards
FlameShield™ Pure Silicone Tape meets many or all of the specifications of the following standards:
MIL-I-46852, A-A-59163, ASTM D412, ASTM D 119,
ASTM D150, ASTM D624, ASTM D2148, ASTM D2240.
FlameShield™ Pure Silicone Tape may also be certified to the following specifications upon request (fees apply):
Commercial Specification A-A-59163 Type I & II (Previously MIL-I-46852C Type I & II), Military Specification MIL-I-22444C,
Underwriters Laboratories Inc UL-510, Boeing DMS2186 Type II, Lockheed Martin MMS J517 & 5-00857, Safe Flight 59562-5
Systems & Electronics Inc ES7889, McDonnell Douglas Helicopter HS5215, General Dynamics P5384 Type II,
General Electric A50A493 / A50E112 / P5384, Rohr RMS315, FAR 25.853, CSA 22.2, Premier Farnell Corp 810112
FlameShield™ Pure Silicone Tape meets many or all of the specifications of the following standards:
MIL-I-46852, A-A-59163, ASTM D412, ASTM D 119,
ASTM D150, ASTM D624, ASTM D2148, ASTM D2240.
FlameShield™ Pure Silicone Tape may also be certified to the following specifications upon request (fees apply):
Commercial Specification A-A-59163 Type I & II (Previously MIL-I-46852C Type I & II), Military Specification MIL-I-22444C,
Underwriters Laboratories Inc UL-510, Boeing DMS2186 Type II, Lockheed Martin MMS J517 & 5-00857, Safe Flight 59562-5
Systems & Electronics Inc ES7889, McDonnell Douglas Helicopter HS5215, General Dynamics P5384 Type II,
General Electric A50A493 / A50E112 / P5384, Rohr RMS315, FAR 25.853, CSA 22.2, Premier Farnell Corp 810112
Price for 1" wide .020" thick tape
Type I is $34.71 per roll
Type II is $33.80 per roll
Certification:
$6.00 per roll
$10.00 per lot / batch
Available in Oxide-Red and Black
Type I is $34.71 per roll
Type II is $33.80 per roll
Certification:
$6.00 per roll
$10.00 per lot / batch
Available in Oxide-Red and Black
